Dual-source evolution, light and shadow overwhelm
Redefining "Cost-Effectiveness" — Moving beyond the mediocrity of ordinary LEDs, CL-2EP sets a new benchmark for compact effect lights with revolutionary performance. "Dual-Source Evolution, Visual Domination."
With advanced CSP packaging technology,
brightness is boosted by 30–40%
In the pursuit of light and shadow artistry, we never cease to ask: how can one fixture unleash a world of brilliance?
CL-2EP is our answer.
More than a lighting tool—it is a vessel for creativity. By merging the vibrancy of RGB with the purity of ALC, we’ve endowed it with unprecedented expressive power. We reimagined its linking structure, transforming it from a solo performer into a synchronized legion. From now on, your lighting design knows no bounds.
Exclusive Backlight Effect, Spliceable Strobe, Versatile Looks
Dual-Core Engine, Unmatched Performance
Title: RGBALC + CSP — Brightness Boosted by 40%*
Say goodbye to mediocre LED performance. At its heart lies an RGBALC 6-in-1 light source with CSP integrated packaging. With a total power of 540W and full-white operation drawing only 200W, it delivers stunning luminosity while consuming less energy and maintaining stable output—offering a visually dominating impact.
Cinema-Level Image Quality,
True-to-Life Visuals
Title: High CRI (90–95%) — Authentic Color Reproduction
Full-spectrum high color rendering ensures true-to-life skin tones and object colors. Whether viewed live or through the lens, the result is a cinema-grade visual experience.
Intelligent Linking, Limitless Possibilities
Our unique quick-lock linking system works horizontally or vertically. A single unit is a versatile tool; linked together, they become a synchronized army. Exclusive linked strobe and backlight effects make grand-scale design simple. The van-type stage vehicle can greatly shorten the time taken for building and tidying up stages and significantly reduce the labor intensity and save manpower
_edited.jpg)
Full-Protocol Control, Total Flexibility
*Title: Multi-Protocol Support, ±20° Horizontal Adjustment*
Fully compatible with DMX, W-DMX, Art-Net, sACN, and more—seamlessly integrating into any control system. The dual heads offer ±20° horizontal adjustment, enabling precise placement and unbounded creativity.
Technical Specs Page
2x475W RGBALC Leds
• 120x0.2W RGB 3in1 led ring
• Max power consumption: 900W
• Constant power consumption: 450W
• Max power consumption 200W@each color
• 19 DMX channel modes
• DMX512, RDM, ArtNet, Auto, Master-slave
• LumenRadio W-DMX wireless (optional)
• Easy to update software via DMX port
• 0~100% linear dimming, flicker free
• Built-in dimmer curves and auto modes
• Can be Interconnected into various combinations
• Die-cast aluminum housing
• IP rating: IP65
• Automatic overtemperature protection
• SEETRONIC IP PowerCON TRUE1 In&Out
• SEETRONIC IP XLR 3pin & 5pin DMX In&Out
Core Selling Points
Feature Dimension
Light Source Core Pitch
Power & Luminous Flux
Color & Image Quality
Special Functions
Splicing Structure
Color Temperature Control
Cost Performance
Exterior Ring
Figure C1-2EP Upgraded Version (RGBALC)
Standard RGBWA 5-in-1
Total Power 540W, Single Color 90W,
Full White up to 200W
High Color Rendering Index, Full Spectrum
Exclusive Backlight Effect, Spliceable Strobe, Versatile Looks
Self-locking Quick Splicing (Horizontal/Vertical)
1800K~10000K, CTO Constant Power Output 2200W
Light Source Cost >5x Higher than Standard Version
Standard Version (RGBWA)
Standard RGBWA 5-in-1
Total Power 200W, Single Color 40W, Full White 200W (Max Load)
Value to You
Brightness increased by 30%-40%, richer colors, more transparent light quality, effortlessly becoming the center of attention.
"More power for remarkable effects" yet more energy-efficient, ample power reserve, stable brightness output without attenuation.
Standard Color Rendering Index
True-to-life skin tones, captured footage is bright and color-accurate, the preferred choice for professional rental houses and live event technicians.
No Backlight
Creates unique visual highlights; backlight sets the atmosphere, splicing achieves synchronized large-screen effects, diverse applications.
Traditional Splicing
Setup speed doubled, more stable structure, easily forms arrays and walls, meets large-scale design demands.
1800K~10000K, Floating Output Power 100W~2200W
Stable output, brightness remains constant when switching color temperatures, ensuring smooth, uninterrupted performances and shoots.
Cost Performance
The C1-2EP is your tool to stand out from low-price competition, achieving both higher rental rates and high customer satisfaction.
RGBWA Outer Ring Pixel Control, Colorful Effects, Diverse Looks
None, Standard Version has no light, single look
Versatile lighting matrix, more stunning visual impact.
Click to download the manual
